I had mentioned this device in a post about DorkboxPDX PCB’s, and didn’t do a post on it, but had some request to. This is the same as my other iPad charger, but this one includes an LDO regulator as well as a barrel jack. I have had a few request for the files, so here is all the info. Happy charging. 🙂
You can find the files at my Github page.
Posted in Cool Stuff, iPad, Open Source Hardware, PCB, SMD, Tools / Equipment
Tagged dorkbot, dorkbotpdx, ipad charger, iphone charger, ldo, pcb, SMD, usb
I was sitting at my dining room table the other night looking at a project, and thought, wow, that Nokia 5110 display would look really good in red! I was right.. Continue reading
Posted in Cool Stuff, LCD, LED, Nokia LCD, SMD
Tagged Adafruit, LCD color change, Nokia, nokia 3310, nokia 5110 LCD, nokia LCD, open source hardware, SMD, SMD rework
So I picked up a new good habit, ordering PCB boards. I know it might sound odd, but it really has become a habit. It started with an iPad charger I made, and now it is much more, and often.
It’s quite a simple process, dream up some neat little board, design it in Eagle, and order it via DorkbotPDX. There are even .dru and .cam jobs for you to use with Eagle, or you can just send the Eagle .brd file if you’d like. About 2 weeks later, you get 3 copies of what you ordered. It’s a fantastic way to get a few PCB’s made to test before ordering a big quantity, or just get a few for a personal project. It only cost $5 per square inch, with no setup fees and free shipping! It’s a great way to get boards made for the first time without the fear of losing a large amount of money involved with minimum quantities or setup fees. I have placed 7 orders and all have been perfect. So what are you waiting for? Give it a go! You can find all of the info on the DorkbotPDX PCB Order page.
For larger boards (150 square inches or more), or 4 layer boards ($10 per square inch), there is also a service. Details on the DorkbotPDX PCB Order page.
Below are some pictures of the boards I have ordered. Click for full res images. Continue reading
Posted in ATtiny, Cool Stuff, iPad, Open Source Hardware, PCB, Tools / Equipment
Tagged board house, custom pcb, dorkbot, dorkbotpdx, laen, open source hardware, pcb, prototype, purple pcb
I had a post a while back on charging an iDevice (iPhone, iPad, iPod) and talked about and showed a schematic for the charging circuit. This design is based (and the schematic is almost exact!) off of Ladyada’s Reverse engineering Apple’s secret charging methods. (video link, it’s good, you should watch it!) I give her full credit for the circuit. Now, the boards I whipped up in a few hours, and had it made from DorkbotPDX service. I sent off the files and 2 weeks later, I got three perfect purple PCB’s. The boards cost a total of $4.69. Shipped. You can’t beat that with a stick! Now, I have a nice little iDevice charger that accepts standard 5 volt power from any standard power supply. Although I do tend to favor 5V 2A supplies from Adafruit.
I used the same circuit I had in the old post, just added an LED and resistor for a power indicator. I had an old cell phone from 2006, and saved the keypad because it lit up blue. (Can you blame me?) Now, 6 years later those tiny 603 blue LED’s come in handy. I got the 603 resistor from an old PC motherboard. Motherboards have a slew of SMD things on them. So I fired up the hot air rework station, grabbed my tweezers, and voila! SMD parts! (I did order some reels of 603 resistors and LED for use in future kits, sorry peeps, no old motherboard parts for you!) I use a good pair of tweezers, and a viewfinder from an old camcorder to inspect my work. “But Jeremy? Where do you keep all of those SMD parts?” you ask? Good question, I use these awesome Modular Snap SMD component storage boxes from Adafruit. They have spring loaded tops, and they are modular, you can form them in any configuration you want! How cool is that?!
Posted in Cool Stuff, iPad, Open Source Hardware, Tools / Equipment
Tagged Charging, eagle cad, iPad, iPhone, iPod, LED, open source, open source hardware, pcb, SMD, surface mount
Control your blinky!!!
Meet the RGBW LED Controller. It is a LED controller that features an embedded ATmega328 with an Arduino bootloader for easy programming, 4 channel LED control with dimming, 5 or 12 volt output, IR receiver, XBee header, RS-232 or TTL serial I/O, 2 push buttons, 12 pin extensions for all unused pins (6 analog and 6 digital), power and channel LED indicators, and dual power input options. You can control 5 or 12 volt LED’s via serial with adjustments to the level of any channel with ramping to the desired level, rate of ramping, color cycle start and stop, rate of color cycle, length of stay on each color during cycle. Fans and motors can also be driven with ease. You can buy one for only $35 with the Paypal link below! Be sure and also visit the complete assembly tutorial! Power supplies, RGB and white LED strips, FTDI Friend or FTDI Cable and XBee’s and XBee adapters are available at Adafruit!
Updates include an additional power input option, more pin options, thicker traces for more power handling, and some slight fixes/adjustments.
I now have an updated downloadable PDF manual with pictures and linked index! 🙂
You can purchase them in the store!
Remember, this is not a shield, it works standalone, without an Arduino!
