I am one who loves to create things. I thrive on a good challenge and work well under pressure. I love to hear someone express a need and then creating a solution for that situation. I enjoy delivering turn key solutions to customers.

My strong suit is circuit boards, most of the time utilizing microcontrollers with code for embedded solutions. I also have made simple projects with the challenge of battery life and space as well as more complex, sophisticated touch screen controllers with a tailor made operating system.

Design for production is also something I have done for over a decade. Accommodating PCB sizes to fit existing cases and applications, schedules, and budgets are all under my belt. I have worked with large and small teams, simple and complex projects, and even reverse engineering to create updated solutions.

I would love to make your product idea a reality. Contact me and we will the gears turning getting your project underway.

Jeremy

TQFP 16? ;)

RGBW LED Controller v3.1

Posted on by

The new RGBW LED Controller is here! The video above shows some of the things it can do, but here is a list of improvements:

IRLB8721PBF MOSFET’s – More power!

Double sided and thicker board traces

More output headers

Cleaner board layout – All power and LED connections on one side – rounded corners

Improved serial capture method with feedback

Support for solid color commands (magenta, cyan, gold, RGB white, orange, light blue, light green, violet, pink, and RGB warm white)

More control from button inputs – long and short press commands

EEPROM memory of LED levels when powered off/on

IR control mode! – Full control of all channels and a memory recall function Get the remote here: http://www.adafruit.com/products/389

Wireless control via XBee! Get an Adafruit XBee adaptor here: http://www.adafruit.com/products/126

Backward compatible! The new software set will work on version 3.0, 2.2, and 1.9!

In stock and shipping from our store now!

New firmware and cad files available at https://github.com/jersagfast/RGBW-31.

The manual is here: RGBW LED Controller v31

RGBW31

JOS – Updated!!!

Posted on by

I did it, I finally found some down time to update JOS to work with current libraries from Adafruit. Below is a link to the new code on Github. A few notes to look at are listed below.

First, this is code for the Touch Shield, but it can easily be changed to the breakout board, and don’t forget to uncomment the ‘#define USE_ADAFRUIT_SHIELD_PINOUT’ line in Adafruit_TFTLCD.h file.

Also, this sketch has pin 3 setup as the backlight on the shield. This way you have PWM control over the backlight. You can accomplish this by cutting the VCC trace and soldering the PIN3 jumper on the back of the shield. You can read more on how to do that here.

This sketch has EEPROM settings, if you have not used them before, the values will be zero and need to be set. There are notes about this in the sketch on lines 92 & 93.

If you don’t know what JOS is, you can check it out here. (What’s a JOS anyway?)

Happy sketching! The code is here: https://github.com/jersagfast/JOS—TFT-Menu-System

Programming the Square Inch – TQFP Jig

Posted on by

First, I am happy to announce that the One Square Inch of Goodness and the FTDI Adapter are in the stock now and available for purchase!

In the video above, I show how I programmed the assembled kits as well as the raw TQFP IC’s without soldering anything to them. It’s a pretty simple setup, but solved the problem I was facing as well as made things a lot faster. As I mentioned in the video, pogo pins are found here, USBtinyISP here, and breadboard switch here (from Adafruit).

A note on using ICSP: – The Square Inch is designed to accept an FTDI connection for programming. Because of this, a .1µF capacitor is between the reset line of the ATmega328P and the pin labeled DTR. This is so when you load new sketches on the Square Inch, it will reset automatically via the DTR line on the FTDI adapter. When you use ICSP, you need to bypass this capacitor! Otherwise it will not work. The programming board I used in the video had the capacitor bypassed with solder (pictured below). There is also a via to the right of the capacitor that leads to the reset line. This can be shorted to the DTR pin to accomplish the same task, as I did to program the assembled boards.  Continue reading →

Really Small(s) GPS

Posted on by

Hi peeps, I have been wanting to make a small GPS device (GPS receiver and some sort of screen) that I could carry around for a while now, but I didn’t want it to be too big, so I made this. Mission accomplished.

This unit is explained in the video above, but is basically a GPS receiver, 1 CR1220 battery for the RTC on the GPS breakout, one of my Square Inch of Goodness boards, one 128×32 OLED display, three 6mm buttons, and a 400mAh Li-Po Battery (from Sparkfun). It even has FTDI headers on it so I can update the firmware with ease (with my own FTDI adapter!). The awesome part is that all of those things fit in an Altoids Smalls tin, measuring 2.15″ (W), 1.35″ (L), and .56″ (H), or 55mm (W), 34mm (L), and 14mm (H).

The GPS breakout board is from Adafruit and uses the MTK3339 GPS module, and man does it work well. I have had other GPS modules that worked, but it was a fight. If you’re thinking about putting GPS in a project, use this. They also have a great library for it. They even have the raw MTK3339 GPS module if you want to use your board. Read the Adafruit product page for all the features, there are many.

The 128×32 OLED display is also from Adafruit, it works well and has the typical OLED crispiness. Very easy to read, even in sunlight, for the size and you can even multiply the text size if you want to.

So I’m going up to NY in a few days, and I wanted a new and exciting way to talk with the TSA folks, so I figured this would work. (kidding) If only Hollywood had not trained everyone to think a gadget with a few wires and a flashing red LED, that they didn’t understand, was a bomb.. ugh. (not kidding)

*UPDATE – there is a set on Flickr for this with teardown pictures.

*UPDATE #2 – Oops, I forgot to put the link to the code on Github. 0_0
